Hydraulic clamp carrier is put though a small wooden plank larger mosaic processing, and improve the utilization of wood is wood flooring and solid wood furniture, timber and other industries essential products.
The specification:
Max. processing thickness | 10-95 mm |
Max. processing length | 2500 mm |
Max.processing width | 1250 mm |
Main motor power | 1.5 kw |
Oil pump motor power | 4 kw |
Working air pressure | 0.6 Mpa |
Row no. | 10 |
Overall dimension | 4980*3900*3800 mm |
weight | 5500kg |
Main feature:
1. The machine equipped with hydraulically operated clamptighteners, providing extremely powerful, uniform and fast clamping performance.
2. Clamp carriers are very simple and most efficient equipment - with maximum rigidity and durability.
3. Every machine has a special steel frame. Large diameter shafts, heavy-duty chains, large cast iron sprockets, and an auto clamp carrier rotation cycle, all of which help to minimize operator fatigue and maximise productivity.
4. Super heavy duty clamps with zinc plated corrosion resistant, rails and screws provide super strength and durability. Clamps have a high jaw.
5. The rear jaw is quickly and easily repositioned for different panel widths.
Product details:
1. Heavy duty worm reducer insures control indexing, even when rotating on unbalanced load. The chain for rotation feeding is heavy duty and stable.
2. Super heavy duty clams, rails and screws provide super strength and durability. Clamps have a high jaw.
3. Hydraulic station, supply enough power to press the wooden boards.
Hydraulic clamp carrier is mainly used in wood floor, timber, solid wood furniture and other industries.
